Name: 700 Field Operations Deployment Design Rapid Command Unit
Uploaded: 2026-04-17T10:46:46+08:00
Description: The dual-wing expansion unit is a rapid command module designed for field combat deployment. The exterior features a military matte coating with low visibility, blending into various field environments.

The dual-wing expansion unit is a rapid command module designed for field combat deployment. The exterior features a military matte coating with low visibility, blending into various field environments.

Parameters:

Wood Grain

Model:

One Bedroom, One Living Room

Expanded Dimensions:

L5900*W4780*H2480mm

Internal Dimensions:

L5660*W4620*H2220mm

Folded Dimensions:

L5900*W700*H2480mm

Total Net Weigh:

1.9 tons

Color:

Customizable

Layout:

Customizable

Area:

27.5 square meters

Inquiry

Write a Review

Core features

● Mobile: Can be towed by a tractor or pickup truck

● Rapid Deployment: Can be set up in 1 hour and put into operation the same day

● Save Shipping Costs: Shipped folded, 6 units per 40-foot container

Download Specifications

0 (6)

Configuration Table

Product Type	Standardized products, capable of customized design
House specifications	Customizable
Structure	Fully Galvanized Cold-Formed Section
Building Maintenance	The standard sandwich core material is 12kg/m³ EPS, 75mm sandwich panel, with 0.35 color-coated steel on both sides (core materials available include rock wool, EPS, and polyurethane)
Ceiling	50mm EPS sandwich panel, 1.0mm thick steel plate
Ground	Fireproof magnesium glass floor 18mm thick, PVC floor covering, 2.0mm / stone-plastic floor 4.0
Door	Standard steel doors (customizable KFC entrance doors, broken bridge aluminum entrance doors, titanium-magnesium alloy sliding doors)
Window	Standard plastic-steel sliding windows (customizable high-end broken bridge aluminum windows and aluminum alloy sliding windows) 9309308 pieces
Kitchen	Standard L-shaped cabinet
Bathroom	Includes partition, shower, washbasin and toilet, mirror, cabinet, sliding shower door, floor drain, and water supply and drainage pipes
Foundation	Concrete isolated foundation

Get Full Version

Configuration Table

Basic Information	Product model	10 feet
	Expand the dimensions	L5900W4780H2480mm	Number of occupants	2 to 3 people
	Internal dimensions	L5660W4620H2220mm	Electric power consumption	12KW
	Folding size	L5900W700H2480mm	Total net weight	Approximately 1.9 tons
	Floor area	27.5㎡
Top of the box	External central ceiling	1.0 millimeter thick steel plate
	Internal roof panel	50mm EPS core board
	Internal ceiling panel	50mm EPS core board
Wall panel	Exterior wall panel	The standard core material is 12kg/m³ EPS, a 75mm sandwich core board, and a double-sided 0.35 mm colored roll (the core materials available include rock wool, EPS, and polyurethane).
	Interior partition panel	50mm EPS core board
Floor	Central floor panel	Fireproof glass-magnesium floor, 18mm thick
	The floor on both sides	Fireproof glass-magnesium floor, 18mm thick
	Floor	PVC floor covering 2.0mm / Stone plastic floor 4.0
Door and window system	Entry door	Standard configuration: Steel doors (Customizable: KFC entrance doors, insulated aluminum entrance doors, titanium-magnesium alloy sliding doors)
	Bedroom door	Steel door / High-end aluminum-wood core door
	Window	Standard plastic-steel sliding windows (customizable to high-end aluminum-veneer windows and aluminum sliding windows) 9309308 units
Electrical system	Breaker system	One leakage protection device, four circuit breakers
	Light	LED round ceiling lamp / recessed lamp
	Socket	On-demand
	Light switch	Double-press switch, single-key switch
	Cabling	Incoming line 6², water heater line 6², kitchen socket 4², air conditioner socket 4², ordinary socket 2.5², lighting 1.5²

Get Full Version

European Mining Area

Colorful sections: 4 colors distinguish different functional areas

Three-story design: Fully utilize vertical space to improve land use efficiency

Fully functional: Built-in air conditioning, toilets, meeting rooms, office area, dormitory

Modular and flexible: 132 containers can be freely combined according to project needs

Highly adaptable: Suitable for remote mining areas or temporary construction sites

High efficiency: Quick transportation, assembly, and disassembly, saving time and costs
